bacteria (LDB) cannot survive without water, and a properly operated, well-maintained HVAC system is unlikely to be a source of problems unless water contaminated with the bacteria enters the system. Air conditioning units without humidifiers have not been identified as sources ofFor a Legionnaires' disease outbreak to be linked directly with the HVAC system, LDB-contaminated water must enter the system, be aerosolized, and be delivered to building occupants. to consider in the system design Operate and maintain all HVAC equipment as originally designed, and maintain it so that it can perform as designed. Minimize use of water reservoirs, sumps, and pans. Provide a way to drain water sumps when not in use, such as, an electric solenoid valve on the sump drain. Provide a "bleed" for water sumps so that dissolved solids do not form sediments in the sump. Slope collection pans and drain sumps from the bottom so that all the water can drain out and allow the pan to dry.

Locate HVAC fresh-air intakes so that they do not draw the mist from a cooling tower, evaporative condenser, or fluid cooler into the system. When evaluating this path, consider: Prevailing wind direction and velocity. Building effects such as low-pressure zones on leeward sides of buildings and on roof. Distance from tower to intake. Design indirect evaporative cooling systems with the knowledge that the failure of the heat exchanger will allow wet systems to mix with the air-distribution systems. Do not use raw steam from the central heating boiler to humidify air because it contains corrosion inhibitors and anti-scaling chemicals. Atomizing humidifiers should have contaminant-free water. to maintain a HVAC system Properly drain all sumps and permanently drain inactive sumps to prevent accumulation of sediments. If an HVAC sump is used during the hours when a building is occupied, drain the sump during unoccupied hours. Maintenance failures can produce stagnant water that can become an ideal environment for

LDB growth if sufficiently warm (such as heated by sunlight). To effectively control contamination, be aware of the conditions that may promote growth and distribute External sources may emit contaminated aerosolized water that is drawn into a system's fresh-air intake. Fresh-air intake airways, typically concrete plenums located at grade level, supplying fresh air to air handlers in the basement or lower levels of buildings can collect organic material (such as leaves and dirt). Aerosols from spray irrigation. Internal sources may provide contaminated aerosolized water that is then disseminated by the air-distribution system. HVAC system humidifiers are potential sources of aerosol exposure if contaminated II:B. Humidifiers and Misters. Direct evaporative air coolers with sprays or misters used as humidifiers include sumps, which may stagnate when not in use. Indirect evaporative air cooling systems using water coils may develop a leak that may inject cooling tower water directly into the supply air stream.

Air-to-air heat exchangers may develop leaks, which may allow the wet air stream to mix with supply air and cause problems if the wet air stream is contaminated withwhy is my window ac unit blowing water Wet evaporative coolers, slinger air coolers, and rotary air coolers with improperly operated and maintained systems that use warm, stagnant sump water may be potential sources ofcover up wall ac unit Residential humidifiers, such as free-standing or portable units, often contain sumps that are frequently contaminated withhvac air conditioner leaking water Computer room air conditioners may contain a humidifier sump filled with contaminated water. Improperly drained condenser pans may produce tepid conditions that can encourage microbial and fungal growth.

Should HVAC systems be sampled? Note: There is no reliable way to detect nonviable LDB in the air. For additional information, see Section II:B. Humidifiers and Misters: Sampling Protocol, and Section II:E. Water Sampling Guidelines: Monitoring. to treat a contaminated system LDB is detected, follow these steps for treatment: Eliminate all water leaks and remove any standing water found in the system to ensure future drainage. Replace or eliminate any water-damaged insulation in the system. Operate the HVAC system using 100 percent outside air for eight hours before returning the building to normal operation. When the building is returned to normal operation, keep outside-air supply rates as high as possible for one month. At a minimum, the outdoor air requirements of ASHRAE Ventilation Standard 62-2001 I.C.E. Custom Commercial HVAC Manufacturing I.C.E. US INC is your source for: Natural and Propane Gas Fired Direct and Indirect Make Up Air Units
