Question about Air Conditioners Remove and relocate split air conditioner Hi, i need to remove and relocate 12000BTU split air conditioner without releasing gas (if possible) from the system without calling a contractor to regas the unit. I am very technicaly minded, i installed the system myself without any problems 1 year ago. Tech. assistance in this matter would be highly appreciated. The simplest way of explaining this is as per the following. On your outdoor compressor unit there should be two pipes, one smaller diameter [high pressure] and a larger diameter pipe [low pressure]. Turn your A/C on inside the house and then shut off the smaller diameter pipe. Run the unit for a around 3 to 4 minutes and then check if the cooling is reducing from the unit inside the house. When you feel room temperature air [not cool] being emitted from the indoor unit shut off the larger diameter pipe and turn off unit. Isolate electrics, disconnect A/C piping and immediately seal the piping with good quality tape to prevent egress of dirt.

When re-installing a quick purge of gas is usually only required to clear the lines if they were sealed properly and kept clean. Ideally running a vacuum pump is recommended but if care was taken then it may not be needed, as in many of my installations. If the unit has king valves you can close the liquid line and pump the refrigerant into the condensing unit. Do not pump the unit into a vacuum. Any remaining refrigerant should be properly recovered by a EPA licensed tech. Move the unit, reconnect (taking care not to allow any moisture or contamination into the lines) and evacuate the refrigerant lines and the evaporator down till it holds 500 microns for 10-15 minutes. The refrigerant can then be released back into the system.your compressor could possibly be a scroll. DO NOT RUN THIS INTO A VACUUM! Testimonial: "Thanks a lot for the info, helped a lot though, better late than never.It's worth a thousand words. How can uninstal and shifting split air conditioner

Apr 05, 2013 | What does p1 means on my 12000btu pioneer inverter mini split ai conditioner? Aug 17, 2012 | I have a 14.4 square metre office room, fitted with 12000btu split AC unit for cooling, will it be sufficient? Feb 01, 2011 | LG LS-L1210CL Mini Split Air Conditioner I have a split unit airconditioner 12000btu.It worked great for about almost 5months.till yesterday,when I turned on the air con,I didn't feel cold.I just felt normal wind blowing.then after 5min a... E-4 ..........short of asor no gasPlease check amps with amps meter reading. If very less amps than specified, it's under gas leak. Even you can physically touch the discharge (small) pipe while running, if it's not warm, gas leak. Call repairman to check and arrest gas leak and then recharge gas. Dec 25, 2010 | We purchased a Amcor Amcoraire Mini Split Unit ? However the Power transformer Output: 10.5v 550mA isn't working as per the installer and we can't seem to find it...

Jun 21, 2010 | Amcor AF 12000E Portable Air Conditioner The best pressure of gas in a split ac in Jun 05, 2010 | LG LSC121PMA Split System Air Conditioner Hi we have a ge air/cond split system which i want to move to another position i know the system does have an accumulator in the main unit i just wanted to know how to reclaim the gas back into the...hvac unit 35 Sep 14, 2009 |ac unit turns off every minute How do i top up the gas (R22) LG gold 12000btuac units for apt Jun 30, 2009 | Mar 25, 2009 | RECOMEDENT SIZE OF ROOM TO USE SPLIT UNITS FROM 12000BTU TO 24000 Not finding what you are looking for?Last year around this time, I began writing a multi-part series on how to inspect your own house. By the time I got to part eight, it was already the end of October and the "cooling" season was well over with, so I never posted part nine.

Last week's post about cheap AC tune-ups reminded me that I ought to finish this series, so here it is. Most single family homes in Minnesota have a split system air conditioner. This consists of a big boxy-looking thing with a fan that sits outside the house, which is connected to a box that sits on top of the furnace through two refrigerant lines; one line is small and runs warm, while the other is larger, insulated, and runs cold. Start your inspection of the air conditioner by making sure that the exterior unit is clean and unobstructed. It dissipates heat by sucking in air on the sides; if it can't do that, it won't operate efficiently. This means no trellis attached to it, no ivy, no plants, etc. Condensing coils also need to be cleaned regularly. When they’re covered with dirt, dust, grass clippings, dryer lint, cottonwood seeds and other outdoor stuff, air flow can be severely hampered. Take the time to inspect all sides of the unit and clean the coils off if necessary.

This can usually be done by spraying the unit down with a garden hose. If the unit has protective grills that prevent access to the coils, the grills will need to be removed first. At that point, a little bit of dismantling is involved, and some homeowners might prefer to contact an HVAC tech to do the work. While inspecting the exterior portion of the unit, make sure it's sitting on a level surface and that the refrigerant lines aren't being stressed. The photos below show some nice examples of air conditioners on top of soils that had settled so much that the units were tipping and the refrigerant lines were being stressed. This is typically a simple fix, as the portion at the outside is usually lighter than most people think, and there is rarely (if ever) anything holding it in place. Older installations typically had the condenser installed on a concrete or plastic pad right on the ground, but most units installed on new homes today are mounted to the side of the house.

The helps them stay cleaner longer, and it usually prevents tipping of the units. Next, turn your air conditioner on by switching the thermostat to cool if it's not already there, and setting the thermostat to a temperature about five degrees cooler than the current indoor temperature. This should get the air conditioner to kick on. To be sure the system is running, look outside and make sure the fan at the condenser unit is turning. If the system doesn't turn on, here are a few things to check which are quite similar to my furnace troubleshooting list, but not identical: If the disconnect has a pair of fuses, test them to make sure they're still good.  If a load-management device, aka a "Saver's Switch" is installed, check to see if it's activated.  Check out this video clip for info on what these are and how to determine if they're working. If you go through that whole troubleshooting list and still can't get your air conditioner to kick on, call a technician.

Once your air conditioner does turn on, go back outside and listen to it. A properly operating air conditioner while make a steady noise. If it makes a surging noise or any noises that seem 'funny', it could indicate a problem with the unit. That would be a good excuse to call a technician. The filter for your air conditioner is the same as the filter for your furnace. It needs to be changed during the summer and winter. A dirty filter leads to reduced air flow, which reduces efficiency and increases the potential for problems. After your air conditioner has been running for about 15 minutes, check the temperature of the air coming out to make sure the unit is cooling properly. Air blowing out of registers always feels cool on your skin, so don't trust the way it feels. Use a thermometer to verify the air conditioner is actually cooling. This will be similar to testing the temperature differential on a furnace; check out my blog post on that topic for more info: A DIY Test for Furnaces.

When checking the temperature differential, measurements should be taken as close to the air conditioner as possible. The difference in temperature between the air going in and the air coming out should be somewhere in the neighborhood of 15 - 20 degrees. If it's much higher or much lower than that, it's probably not cooling properly and it’s time to call in a pro. An air conditioner’s two jobs are to remove heat and remove moisture from the air. Condensation occurs at the box that sits on top of the furnace. This box is called the evaporator coil, and it’s usually shaped like the letter “A”, so it’s often called an “A-coil.” There’s a concealed drain pan below this coil which connects to the condensate drain line. That’s where all the condensate, aka water, goes. If the condensate line gets clogged or obstructed, you’ll end up with a big mess which could cause damage to the furnace, and possibly parts of the building. Keep the condensate line clean to help prevent this.

To make sure there aren’t any hidden condensate leaks above the furnace, remove the blower door to your furnace and look inside that compartment for moisture. If you find moisture, you have a condensate leak, which is probably the result of a clogged line. If you’d like to try clearing a clogged condensate line yourself, or you enjoy squeezing blackheads and you'd like to do the equivalent for your air conditioner, check out this blog post with some great DIY advice: How to clean the AC condensate line. Just ignore the part about most units draining to the outdoors; most units here in Minnesota drain to a floor drain or a condensate pump. That’s about all I can think of when it comes to homeowner inspections of the air conditioner. In last week’s blog post I gave some advice on how to find a good HVAC contractor at the end, and of course I had a bunch of people ask who I’d recommend. I recommend BWS Heating & Air Conditioning. They recently replaced my neighbor’s furnace, as well as our office manager’s air conditioner, and both of them thought BWS was great.
