Our ever expanding list of articles on HVAC/R products and processes will help you get more performance out of your tools, and more time out of your day. The Evacuation and Charge Process A vacuum pump is used to remove air and contaminants from an HVAC system, creating a vacuum state. It is important to note that a vacuum pump is not a recovery unit. A recovery unit should always be used to make sure the refrigerant is recovered from the system before you begin the vacuum process. A vacuum can help protect your system from contaminants and non-condensable gases, which can damage HVAC system components, reduce system efficiency and even cause failure. A vacuum pump “pulls” air, moisture and contaminants out of the system after it has been repaired and before it is recharged. The deeper and more complete the vacuum, the more contaminants trapped within the system components and even in the compressor oil are removed. Prior to pulling a vacuum and charging an HVAC system, you’ll want to recover, repair and check for leaks.

Assuming that these items have been checked off your list, you’re ready to safely evacuate.prices of ac units for home Before starting, fill the vacuum pump with vacuum oil. how to hide indoor air conditioner unitRemove the cap, open the fitting and begin pouring. new ac unit runs constantlyKeep pouring the oil until the oil level reaches the oil line. Here you’ll benefit from a large oil fill port and sight glass, which gives you the benefit of being able to see when the oil reaches the appropriate level. It is important to note here that the quality of your vacuum pump performance is directly related to the quality of your vacuum pump oil. The cleaner your oil, the better your pump’s performance. We recommend high vacuum mineral-based oil be used in all pumps regardless of the type of oil that is used in the system.

Once you can see through your sight glass that you’ve reached the proper oil level, put the fittings back on, or, if desired, attach the exhaust filter. Remove the Schrader cores (if present) with the core removal tools. Install the test and charging manifold. Connect the hoses from the manifold to the system.  Connect the low side (or blue hose) to the low side core removal tool and high side (or red hose) to the high side core removal tool. If you’re using a four-valve manifold, connect the 3/8” hose from the vacuum port on your manifold to the 3/8” port on the vacuum pump. Connect the 4th hose from the manifold to the refrigerant cylinder. If you are using an extension cord, make sure you are using the proper gauge for your pump. Plug in the power cord for the pump. Open all manifold valves and make sure the vacuum valve and core removal tool ball valves are open.For cold weather starts, open the intake port until the pump reaches running speed and then close it off.

You are now pulling a vacuum. It is important that the oil level remain steady when the pump is running for proper operation – about 1/2 to 5/8 up in the sight glass. If it falls too low, the vacuum pump could be damaged. If it’s too high, it will increase the oil in the exhaust. Once you have pulled a vacuum that meets the manufacturer’s specifications, you can close the valves on the core removal tools. Observe the vacuum gauge. It is normal operation for a rise in microns to occur. However, if the rise continues to atmosphere (760,000 microns), there is a leak in the system. Check the system manufacturer’s recommendation for tolerance. Once you are satisfied with the reading, close the valve that connects the manifold to the pump. You can now shut off and disconnect the vacuum pump. Your evacuation process is complete and you are ready for system charge. To charge, open the valve on the refrigerant cylinder. Add enough refrigerant to create a small positive pressure in the system – about 3 psi on the low side.

Remove the digital vacuum gauge and complete the charging process per the manufacturer’s specifications. Once the charge is complete, you can replace the valve cores and remove the vacuum valve and core removal tools. It’s a good idea to simply replace Schrader valves, as they are not that expensive and new valves will reduce the likelihood of system leaks. Screw them back in and seat them properly. Remove your tools and you are ready to go. Connect a digital vacuum gauge for accurate vacuum measurement. The best place to measure vacuum is at the system, not at the pump. With a combination vacuum and charging valve on your core removal tool, you can attach the electronic vacuum gauge directly to the system and isolate it from the pump, hoses and manifold for a true indication of the vacuum in the system. If you suspect an open or wet system, be sure to use the gas ballast feature on your vacuum pump. The gas ballast prevents water vapor from condensing in the vacuum pump oil by introducing a small amount of fresh air into the pumping chamber.

Open the gas ballast just slightly and then begin to watch your electronic vacuum gauge. If the vacuum stays at a consistently high level of microns or doesn’t pull down below 5,000 microns, your system still contains contamination or has a leak. Repair the leak before proceeding. A way to speed the vacuum process is to use a heat gun. This warms the molecules and gets them to leave the surface sooner, speeding the flow of vapor molecules to the pump. Remember to be careful because they do get hot and will take paint off systems.Refrigeration and air-conditioning end-uses typically use a refrigerant in a vapor compression cycle to cool and/or dehumidify a substance or space, like a refrigerator cabinet, room, office building, or warehouse. Chillers typically cool water, which is then circulated to provide comfort cooling throughout a building or other location. Chillers can be classified by compressor type, including centrifugal, reciprocating, scroll, screw, and rotary compressors.
