Driving around in triple digit weather in Utah can be downright unbearable without a working vehicle air conditioning (AC) system. Ace Auto Repair in Utah offers affordable rates and honest, reliable car AC repair every time! Call (801) 803-6016 to Schedule a FREE Air Conditioner Performance Check today! Vehicle A/C Evacuation and Recharge Service Mechanic If the air coming out of your vehicles’ vents is not as cold as it used to be, the issue may be that your car has run low on refrigerant ( R-12 Freon in older cars, R-134a in 1995 and newer cars).  As time goes on, small amounts of refrigerant leak from the system and if there is not enough refrigerant, the AC will not blow cold air. For low Freon levels the solution is simple – put more refrigerant in the system. Recharging your vehicle with refrigerant can bring up the pressure to correct levels. If your vehicle’s AC system is working but not blowing cold air, a refrigerant recharge will give your system back a frosty punch.

If your vehicle AC unit is completely dysfunctional, it is best to take it in to an experienced Utah AC Repair and Recharge Mechanic. There are a number of signs that may signal you that your vehicle’s AC system is not working properly. Some indications that your vehicle AC is having issues may include: AC is blowing hot air AC only works when driving and not when the car idlesair handling unit for home Low air flow coming from ventscost to replace ac unit home Mildew smell coming from the ventshow good are york ac units Signs your AC may begin to lose its’ cool include: Damaged or failed condenser Damaged or failed evaporator Leaks in system seals – core case seals, blower house seals &/or evaporator core case seals

Hose came loose or damaged Vehicle AC Not Working? Ace Auto Repair Will Help Keep You Cool You car’s air conditioning system may have a number of reasons why it is not blowing cold air. By catching problems early on, you may be able to prevent small problems from becoming larger. Regular maintenance will keep your AC system operating at peak performance! When you bring your vehicle to Ace Auto Repair, we will perform a comprehensive inspection of your car air conditioning system includes: Testing for proper Freon levels Testing for Freon contamination Checking the system for refrigerant leaks Inspect AC belts, seals and hoses for damage Car Air Conditioning (AC) Repair Utah If your vehicle’s air conditioning system is not up to par, contact us for a free repair quote. We service all types of car, trucks, vans, and RV’s. To have your air conditioning system recharged, repaired, or replaced by experts consider Ace Auto Repair in West Jordan, Utah.

We are dedicated to giving our customers the absolute best service value available for the vehicles we work on. We stand behind all work that we do with and all work is guaranteed. Stay Cool – Schedule an A/C Performance Check in Utah at Ace Auto Repair!Show All ItemsStep 1: freon checkShow All Items You will need a set of manifold gauges to check you freon pressure. Here are some general guideline for A/C system pressures and temperatures based on ambient outside temperature. Remember that these are a guideline and your actual temperatures and pressures will vary depending on humidity in the air and the condition of your system. When running the car at idle to check the freon level it is a good idea to have a water hose handy and spray water on the a/c condencer. The condencer is located in front of the radiator. For vehicles currently running with freon R-134a onlyOutside-----low side-------High side------Center vent temp 60 F -----28-38 psi----130-190 psi ----44-46 F 70 F ------30-40 psi ---190-220 psi ----44-48 F 80 F ------30-40 psi ---190-220 psi ----43-48 F 90 F ------35-40 psi ---190-225 psi ----44-50 F100 F -----40-50 psi ---200-250 psi ----52-60 F110 F -----50-60 psi ---250-300 psi ----68-74 F120 F -----55-65 psi ---320-350 psi ----70-75 F_You can also use this good rule of thumb with R134a

, run fan on High with all windows open and engine at 1500 rpm. High side pressure in PSI should be about 2.2 to 2.5 times outside air temperature in degrees F. Example if it's 90 degrees F, high side should be no higher than 225PSIHere is a useful trouble shooting chart for systems currently running on freon R-134aTrouble shootingLow Compressor Discharge Pressure1. Leak in system 2. Defective expansion valve 3. Suction valve closed 4. Plugged receiver drier 6. Compressor suction valve leaking 7. Bad reed valves in compressorRepair1. Repair leak in system 2. Replace reed valvesHigh Compressor Discharge Pressure1. Air in system 2. Discharge valve closed 4. Insufficient condenser air 6. Loose fan belt 7. Condenser not centered on fan or too far from radiatorRepair1. Remove some refrigerant 5. Install large fan 6. Tighten fan belt 7. Center and check distanceLow Suction Pressure1. Worn compressor piston 3. Compressor head gasket leaking 4. Kinked or flattened hose 5. Compressor suction valve leaking 6.

Moisture in system 7. Trash in expansion valve or screenRepair1. Replace head gasket 4. Change valve plate 6. Replace drierHigh Suction Pressure1. Loose expansion valve 2. Expansion valve stuck open 4. Compressor reed valves 5. Leaking head gasket on compressorRepair1. Remove some refrigerant 3. Replace expansion valve 4. Replace reed valves 5. Replace head gasketCompressor Not Working1. Broken clutch wire or no 12v power 3. Broken compressor piston 4. Bad clutch coil 6. Low Refrigerant - low pressure switch has cut off clutch powerRepair1. Repair wire or check for power 3. Replace clutch coil 6. Add refrigerantEvaporator Not Cooling1. Frozen coil, switch set too high 2. Drive belt slipping 3. Hot air leaks into car 4. Plugged receiver drier 5. Capillary tube broken 6. Shortage of refrigerant 7. High head pressure 8. Low suction pressure 9. High suction pressure 10. Defective expansion valve 11. Turn thermostat switch back 2. Check for holes or open vents4. Replace expansion valve 6. See problem #2 8.

See problem #3 9. See problem #4 10. Replace expansion valve 11. Evacuate and replace drierFrozen Evaporator Coil1. Thermostat not set properly 3. Set to driving condition 3. Check for excessive duct hose length, kink or bend.If you can't get your a/c to turn on then use this chart to determine if you are low on freon. Remember that this is a general char and will very for different makes and model cars and refrigeration units Temperature -------------------134a Pressure(Psig) -60.0----------------------------------21.6* -55.0 -----------------------------------20.1* -50.0 ---------------------------------- 18.5* -45.0 ----------------------------------- 16.7* -40.0 ----------------------------------- 14.6* -35.0 ----------------------------------- 12.3* -30.0 ----------------------------------- 9.7* -25.0 ------------------------------------ 6.7* -20.0 ------------------------------------ 3.5* -15.0 ------------------------------------ 0.1 -10.0 ----------------------------------- 2.0 -5.0-----------------------------------------4.2 0----- ------------------------------------- 6.5 5.0 ---------------------------------------- 9.2 10.0 ----------------------------

--------- 12.0 15.0--------------------------------------15.1 20.0 --------------------------------------18.5 25.0 ------------------------------------- 22.2 30.0 --------------------------------------26.1 35.0 --------------------------------------30.4 40.0---------------------------------------35.1 45.0---------------------------------------40.1 50.0 --------------------------------------45.5 55.0---------------------------------------51.2 60.0--------------------------------------- 57.4 65.0----------------------------------------64.1 70.0--------------------------------------- 71.1 75.0 ---------------------------------------78.7 80.0--------------------------------------- 86.7 85.0--------------------------------------- 95.3 90.0 ------------------------------------ 104.3 95.0--------------------------------------114.0100.0 -------------------------------------124.2105.0--------------------------------------135.0110.0--------------------------------------146.4115.0--------------------------------------158.4120.0--------------------------------------171.2125.0--------------------------------------184.6130.0--------------------------------------198.7135.0------------------------------------- 213.6 140.0--------------------------------------229.2145.0 ------------------------------------- 245.5150.0-------------------------------------- 262.9155.0-------------------------------------- 281.1160.0---------------------------------------300.0- (in Hg) Vacuum« PreviousNext »View All Steps Download
